Galvanized Steel Grating Panels Hot Dip Galvanized, According to BS 4592
In the contemporary realm of industrial solutions, the galvanized steel grating stands out as a paramount utility. Welded from cross-arranged flat steel and horizontal bars, our grating is a testament to intricate design and impeccable engineering.
Material
The backbone of our steel grating lies in its core material. Predominantly crafted from high-grade Q235A or the robust HDG steel, it ensures durability, even under demanding conditions.
Type
Galvanized steel grating can be divided into various types such as ordinary flat type, anti-skid tooth type, cross-section I type, etc. The realm of galvanized steel grating is diverse, and Weihao Co. covers the spectrum. From the ubiquitous flat type, the ergonomic anti-skid tooth type to the robust cross-section I type, our inventory caters to a plethora of industrial needs.
Use
Beyond its primary function, the uses of our steel grating are manifold. With optimal ventilation, light transmission, and a non-slip surface, our grating solutions cater to varied needs. Whether it's shipyards requiring sturdy platforms, power plants demanding resilient surfaces, or sewage treatment plants needing non-slip gratings, our product stands tall.
Classification
Diverse needs require diverse solutions. Hence, our gratings are classified into:
- Platform Grating for wide-scale industrial applications.
- Safety Mats/Mattress ensuring worker safety and comfort.
- Heavy-Duty Gratings designed for high-load areas and rigorous conditions.
Standard
Standards are not just benchmarks; they are a testament to quality. Weihao Co. leaves no stone unturned in adhering to international standards, notably BS EN: 4592 for our welding processes and design stipulations.
Characteristics
- High Load-bearing yet Lightweight: Our galvanized steel grating strikes a perfect balance between strength and weight. Engineered to bear substantial loads, its lightweight nature ensures ease of hoisting and installation.
- Aesthetic Brilliance: Our steel grating, with its sleek design and polished finish, is proof of that philosophy. Not only does it serve its primary functional purpose, but its appealing appearance also enhances the overall aesthetic of any facility it graces.
- Durability and Anti-corrosion: The longevity of our steel grating is achieved through our rigorous hot-dip galvanizing surface treatment. This process not only bestows the grating with a radiant surface gloss but also imparts a high resistance to corrosion. Such durability ensures that Weihao Co.'s steel grating remains a long-term asset to any establishment.
- Ventilation, Lighting, and Heat Dissipation: Beyond its primary roles, the intrinsic design of our galvanized steel grating facilitates optimal ventilation and light transmission. Post-welding, the grating showcases excellent heat dissipation properties, ensuring a safer and more comfortable environment.
- Safety Features: Safety stands paramount in industrial applications, and our steel grating embodies this principle. With inherent explosion-proof and anti-slip properties, it provides a secure platform, reducing potential hazards. Furthermore, its design actively prevents dirt accumulation, further contributing to a safer workspace.irrespective of the destination.
Customized Specification Products
From specific dimensions, unique designs, to specialized materials, our bespoke solutions have catered to myriad industries, underlining our versatility and commitment to customer satisfaction.
Galvanized Steel Grating Panels
Grating, Hot Dip Galvanized, serrated to BS 4592, Size 19ft x 3ft
Rectangular pattern with hexagonal or square twisted cross bars.
- Size of bearing bars: 40mm x 5mm serrated.
- Spacing between bearing bars: 30mm, connected together
with 8mm hexagonal twisted rod every 100mm.
- Top surface of bearing bars shall be serrated.
- Grating panels shall be hot dip galvanized of minimum 460GM/M ^ 2.
- Pitch of cross bars: 50mm.
- Grating suitable for Max. SPAN 67" for 1/4" deflection under uniform working load of 6.6 KN/M ^ 2.
- The grating bar shall be closed end.
Common grating dimensions: 1" x 1/8" x 36" x 24"
Sheets of Galvanized Grating
Details:
Sheet dimensions:
2400mm load bar length
1200mm sheet width
Thickness: 32mm x 5 Flat bar
Galvanized Steel Platform Grating - Grid Safety Mats / Mattress
32x5 - 45kg per square meter, including fastening mat
Galvanized grates 30/5 type, heat galvanized
Grate step: 240x800
Details:
Stair tread with non-slip reinforced nosing
Hot dip galvanized
Mesh: 30x40
Bearing bar: 30x4 including fastening material
Heavy Duty Galvanized (Hot Dip) Steel Gratings
Size of the grating – 925mm x 1000mm
Square Cross Bar – 10 mm x 10mm
Bearing Plate – 120mm x 6mm thickness
Opening (pitch size) – 45mm x 45mm
2 sides with C Channels, size 100mm x 50mm x 5mm
Fabrication works includes notches/cut-outs
Galv: Hot dip galvanizing after fabrication
Welding specification as per BS EN: 4592
Galvanized Steel Bar Gratings
Sizes:
Resisting side 1310 mm
Mantled side 1695 mm
Open mesh 33x66mm
Side bar 30x2mm
Frame bar on the end of the resisting sides 50x2mm.
For years, as a manufacturers and exporters, we've not just delivered a product; we've delivered a promise – a promise of quality, durability, and unmatched service. Entrust us with your requirements, and be a part of the Weihao Co. journey.
