Heavy Welded Bar Grating-Galvanized Steel Welded Grating Panels
Welded steel grating, crafted from flat steel and cross bars spaced appropriately and fused by welding, offers anti-slip, robust load-bearing capabilities, and excellent ventilation and light transmission. Aesthetically appealing, durable, and straightforward to maintain and install, it's pivotal in modern industrial domains.
Features
- Strength & Lightweight Design: While it's crafted from lightweight steel, its welding process imparts a high-strength, light structure capable of bearing substantial loads.
- Durability & Corrosion Resistance: Post-galvanization, it becomes rust-resistant. Its cross-arranged design further augments stability and bearing capacity.
- Sleek Appearance: With a glossy, smooth surface post-galvanization, it radiates simplicity and elegance.
- Effective Drainage: Its grid design ensures proper ventilation, preventing accumulation of dirt, rain, snow, or water.
- Ease of Installation & Maintenance: Modular by design, it's user-friendly and resilient to pressures and impacts. Overall, it's a robust, aesthetically pleasing, and easy-to-maintain steel product.
Applications
- Industrial Realm: Predominant in shipbuilding, petrochemicals, machinery, and power sectors. In chemical industries, it aids in sewage treatment, filtering, and storage, showcasing impressive permeability, stability, and resistance to pollutants.
- Construction: Ideal for stairways, railings, and fencing, it can be tailored for aesthetics and safety. It also finds use as a decorative element, enhancing architectural designs.
- Transportation: Apt for bridge decks, tunnel barriers, and road plates, its strength and wear resistance optimize vehicular stability and safety.
- Environmental Protection: Essential in pollution control equipment, it's vital at waste sites and treatment plants, effectively preventing pollutant leaks and safeguarding the environment.
Material
Our Welded Steel Grating is predominantly:
Composed of high-grade Q235A or resilient stainless steel, ensuring longevity and resistance to external pressures.
Treated with a galvanization process, it boasts a high anti-corrosion ability, giving it not just a captivating surface gloss but also a promise of durability.
Customized Specification Products
Tailored Dimensions: Recognizing that spaces vary, our gratings can be customized to fit exact dimensions without compromising structural integrity.
Unique Designs: From varying the distance between bars to implementing unique patterns, our design team collaborates closely with clients to bring their vision to fruition.
Specialized Features: Depending on the application, features such as enhanced anti-slip properties or specific load-bearing capacities can be integrated.
Heavy Welded Bar Grating
Galvanized steel welded grating panels
Width 24", Span 60"
1/4" x 1" Bearing Bars, 1-3/16" center to center spacing.
Heavy welded cross bars on 4" centers
Smooth surface, Load Banded with equal gauge stubs welded ends.
Flat Bar Grating welded, hot dipped galvanized finish
Material: Carbon Steel with galvanized finishing
Panel Width x length:Im x 6m
Details:
Non-serrated/smooth bar grating.
Bearing bar size: 1-1/4"x 3/16"
The bearing bars 19/16's(1-3/16)inches on center
Cross bars spaced at 4 inches on center.
Types of bearing bar: Flat bars; made from steel strip or slit sheet, or rolled.
Finishing:Hot Dip Galvanizing, zinc coating minimum average coated per Standards AS1650,BS729 and ASTM A123.
Welded Metal Bar Grating - for Oil and Gas Industry
Industrial grating, welded, details:
Sheet size 6100 (6000) x 1000mm
Cell size 34x38 / 30x3 mm
Material: Steel S235
Finish:Corrosion-resistant, hot-dip galvanized by EN ISO 1461: 2009
No borders
Dimensions in accordance with RAL GZ 638
Standard: DIN 24537-1:2006-04, DIN 24531-1
WSG-1 Welded Steel Grating
WSG-2 Welded Steel Grating
WSG-3 Welded Steel Grating
WSG-4 Welded Steel Grating
